In the pump and valve industry, the name "2507" is deeply ingrained in people's minds when it comes to high-end corrosion-resistant materials. It represents superior performance and adaptability to harsh working conditions. But did you know that the standards for "2507" used in pipes/plates are completely different from those used in pump and valve castings? This seemingly subtle difference may be putting your company at significant risk of safety issues and economic losses.

The Origin of 2507: One Name, Two Standards

2507 was originally a commercial grade of super duplex stainless steel, SAF2507, introduced by the Swedish company Sandvik in the 1980s. By increasing the content of chromium (Cr), molybdenum (Mo), and nitrogen (N), its corrosion resistance (especially the PREN value exceeding 40) far surpasses that of traditional stainless steels, while also possessing extremely high strength, making it an ideal choice for extreme working conditions such as marine engineering and petrochemicals.

Due to its outstanding performance, the composition specification of 2507 has been included in the globally authoritative ASTM (American Society for Testing and Materials) standard. It is categorized into two separate standards based on different product forms:

• Rolled steel standard: Applicable to steel plates, strips, and other products, it is included in ASTM A240, with the unified designation S32750. This is usually the grade we refer to when broadly discussing 2507.
• Casting standard: To meet the manufacturing requirements of complex-shaped products such as pumps and valves, its composition is included in ASTM A890, with a material grade of Grade 5A and the unified designation J93404.

Simply put, A240 S32750 is the "rolled version" of 2507, while A890 Grade 5A is its "cast version." 2507 is just a name, not a trademark, and can be widely used without being associated with any particular manufacturer.

Key difference: Why do castings require a higher molybdenum content?

Although they both originated from the same source, their chemical compositions, especially the content of the core corrosion-resistant element—molybdenum (Mo), differ significantly in order to adapt to different manufacturing processes.

Element	A240 S32750 (2507 rolled product)	A890 Grade 5A (casting)	Influence on corrosion resistance
Chromium (Cr)	24.0-26.0%	24.0-26.0%	Same. Provides basic corrosion resistance and passivation capabilities.
Nickel (Ni)	6.0-8.0%	6.0-8.0%	Same. Provides basic corrosion resistance and passivation capabilities.
Molybdenum (Mo)	3.0-5.0%	4.0-5.0%	Grade 5A has a higher lower limit. Molybdenum is the most critical element for resisting chloride ion pitting corrosion, and a higher molybdenum content ensures strong resistance to pitting corrosion.
Nitrogen (N)	0.24-0.32%	0.10-0.30%	S32750 has a higher lower limit and range. Nitrogen can significantly improve pitting corrosion resistance and stabilize the austenitic phase. However, high nitrogen content can introduce the threat of porosity.

The dangers of confusing standards: It's not just about "cutting corners."

Pump and valve products are primarily manufactured using casting processes and should therefore adhere to the A890 Grade 5A standard. However, some manufacturers, in an effort to save costs, exploit the market's vague understanding of "2507" and use the A240 S32750 composition specification to produce castings, controlling the molybdenum content to around 3.0%. The consequences of this practice are disastrous:

1. 1. The "weakest link effect" leads to a sharp reduction in lifespan: During the cooling process of castings, the distribution of alloying elements becomes uneven (microscopic segregation). If only 3% molybdenum is used, the actual molybdenum content in some areas will be far lower than this value, forming corrosion-resistant "microscopic weak points." The entire lifespan of the pump/valve will be determined by these weakest points.
2. 2. Failure modes become unpredictable: Such pumps/valves do not corrode uniformly, but rather experience rapid pitting, perforation, or crevice corrosion at weak points. This means that the equipment may appear intact on the surface, but suddenly leak at a critical location. This type of failure is sudden, cannot be predicted through routine inspections, and can easily lead to safety accidents.
3. 3. Fatal process defect risk: Forcing casting with a high-nitrogen rolled material composition can easily create internal pores that are difficult to see with the naked eye. These pores become sources of corrosion, significantly reducing the density and reliability of the casting.

In other words, the composition of A890 Grade 5A is an optimized solution "tailor-made" for the casting process, designed to ensure that the final product consistently meets the stringent performance standards of super duplex steel, even with inherent microscopic variations.

How to mitigate risks and ensure your choice is foolproof?

As end users, the best way to protect our own interests is to raise awareness and take strict control measures:

• Clearly define procurement standards: For pump and valve castings, the standard must be explicitly specified as ASTM A890 Grade 5A (UNS J93404) in the procurement contract and technical specifications. Simply stating "2507" is unacceptable.
• Strictly review material reports: Upon receiving the product, carefully verify the accompanying Material Test Report. Three key items to check: Is the standard A890 Grade 5A? Is the Mo (molybdenum) content ≥ 4.0%? Is the PREN value ≥ 40? Any casting below these values, regardless of the supplier's explanation, should be considered unqualified.
• Implement incoming inspection: For particularly critical equipment, it is recommended to use a handheld spectrometer for random inspection upon arrival to verify key chemical components on-site. This is the most direct and effective means of identification.
• Choose reputable suppliers: Never consider price as the sole factor. The long-term value, operational safety, and professional assurance provided by a reliable supplier are far more important than initial price differences.

With a clear understanding and strict quality control, you can ensure that the selected "2507" is a qualified material that is truly suitable for your working conditions and can provide long-term safety assurance.
