Incoloy 800 and 800H/HT are different variants of the same base alloy. The main differences lie in carbon content, heat treatment process, and high-temperature performance.

In simple terms, 800H/HT is a refined version of 800. It contains more carbon and undergoes a stricter heat treatment. This combination creates a coarse-grain structure, which gives 800H/HT far better resistance to creep at high temperatures.

Differences

Property	Incoloy 800 (UNS N08800)	Incoloy 800H (UNS N08810)	Incoloy 800HT (UNS N08811)
Carbon Content	0.03% – 0.10% (medium)	0.05% – 0.10% (higher)	0.06% – 0.10% (highest)
Al + Ti Content	≥ 0.30%	≥ 0.30%	≥ 0.85% (enhanced)
Heat Treatment	Annealed above carbide solubility temperature, followed by rapid cooling	Must be annealed at a minimum of 2100°F (1149°C), then rapidly cooled	Same as 800H, annealed at ≥ 2100°F (1149°C), then rapidly cooled
Grain Size	No mandatory requirement	ASTM 5 or coarser (larger grain size)	ASTM 5 or coarser (larger grain size)
Key Features	Balanced performance, excellent corrosion resistance	Improved high-temperature creep and rupture strength	Further enhanced high-temperature strength and creep resistance due to higher Al+Ti
Common Applications	Chemical processing, heat exchanger tubes, nitric acid production units	High-temperature furnace components, cracking furnace tubes, heat exchangers, radiant tubes	Severe high-temperature environments such as petrochemical cracking furnace outlets

The Core Difference

The biggest difference is in high-temperature performance, which is also the most important factor for material selection.

The mechanical properties of Incoloy 800 and 800H/HT may be similar at room temperature, but at elevated temperatures (typically above 600°C / 1112°F), the performance gap becomes significant:

• 800H and 800HT offer much better high-temperature strength, creep resistance, and rupture resistance compared with standard 800.
• 800HT, with its higher Al+Ti content, generally delivers the best high-temperature performance among the three.

For applications where long-term strength at extreme temperatures is critical, 800H and 800HT are superior choices.

Application Fields

Incoloy 800 is suitable for:

• Reactors and piping in chemical plants
• Heater tubes and exchangers in nitric acid production
• Superheater tubes in nuclear facilities

Incoloy 800H/HT is tailored for:

• Ethylene cracking furnace tubes
• Radiant tubes and combustion chambers
• Industrial kilns and reformer tubes
• High-temperature heat exchangers

Material Selection Guide

1. Incoloy 800 – A versatile alloy with reliable corrosion and heat resistance. Best for balanced performance.
2. Incoloy 800H – An upgraded grade with higher carbon and controlled heat treatment. Designed for strength under stress at high temperature.
3. Incoloy 800HT – The top tier in this series. Enhanced with more Al+Ti for the highest resistance to creep and rupture.
