AISI 304 EN 10357 Welded Tube

Product Description

SUNNING STEEL LIMITED offers AISI 304 EN 10357 welded tubes, engineered to meet the rigorous demands of hygienic and sanitary applications. Manufactured in compliance with EN 10357 standards, these tubes are widely used in food processing, dairy, beverage, cosmetic, and pharmaceutical industries where hygiene and cleanliness are paramount.

Made from austenitic stainless steel 1.4301 (AISI 304), the tubes are TIG-welded, pickled, and mechanically polished inside and outside to achieve a highly smooth, crevice-free surface finish (Ra ≤ 0.8 μm or better on request). This minimizes contamination risk and ensures superior corrosion resistance, even under demanding CIP (Clean-in-Place) and SIP (Sterilize-in-Place) cleaning cycles.

Product Parameters

Standard	EN 10357 (formerly DIN 11850 / ISO 2037)
Material Grade	AISI 304 / 1.4301
Standard OD	10 mm – 104 mm (non-standard sizes available upon request)
Wall Thickness	1.0 mm – 2.0 mm
Length	Standard 6 meters (custom lengths available)
Weld Type	TIG welded, bead rolled, and heat-treated
Surface Finish	Inner & outer polished, Ra ≤ 0.8 μm (or customized)
Tolerances	According to EN ISO 1127 / D4/T4
Marking	Laser marking available as per customer requirement

Application Range

• Food & Beverage Processing Plants(Milk, beer, juice, mineral water, soft drinks, edible oil)
• Dairy Industry
• Pharmaceutical & Biotechnology
• Cosmetic & Personal Care Manufacturing
• Breweries & Wineries
• Clean Room & Sterile Environments
• Hygienic Distribution Systems

Performance Highlights

• Corrosion Resistance
  Excellent resistance to common food-grade acids, cleaning agents, and oxidizing environments.
• Hygienic Finish
  Interior and exterior polishing prevents bacterial build-up and ensures sanitary operation.
• Robust Mechanical Properties
  Well-suited for piping systems operating under either pressure or vacuum.
• Weld Integrity
  Smooth inner welds free from cracks and pits enhance cleanability and flow.
